2009 Corolla S Turbo Thread Build

#1
I just ordered my new turbo kit for my 2009 S from turbokits.com. I was able to visit there shop in Connecticut in September. I was very impressed with the shop and the owners Grant and Jesse were amazing showing me around. I ordered the kit with a few extra features too. It's supposed to be shipping out this week!

1. Billet turbo wheel upgrade
2. Ceramic coated exhaust manifold, turbo and downpipe
3. 3" complete SS exhaust
4. 3" intake pipe

I'll also be the first one that is getting my OEM ECU tuned by Orange Virus. They have unlocked the Toyota ECU for my Corolla so I don't need to use a piggyback so it will be as reliable as a OEM turbo setup.


I got a baseline dyno run showing 126 HP on the first run.




Bought some gauges too.





#4
Progress has been going well now that the Christmas holiday is winding down. I've been able to get the exhaust manifold & turbocharger mounted, water & oil lines connected, new upgraded fuel injectors installed. I've dropped the old exhaust system too. Next up is working n mounting the intercooler and piping. :cool:








#5
It's been a very long, cold winter which has made it hard to work on my turbo project. After taking a trip to Hawaii, which was awesome, I was able to make some progress on my Corolla.

Got the IC all mounted up.


View of the IC from above.


Inlet to the IC.


IC piping from the turbo under the engine toward the IC.


IC piping from the IC toward the intake.


You can also see the air filter pipe inlet that leads to the turbo.


I've also started on the vacuum tubing to the wastegate, BOV, boost gauge and AEM FIC.

#7
I was able to get all of the wire harnesses for my 3 gauges pulled through the firewall today! I'm so very excited. Hoping to get them finished off tomorrow. I can then get the AEM FIC hooked up and start checking all of my connections and bolts before I fire it up for the first time! Oh so close. Almost set for TURBO TIME!!!! >:D

#8
I had to extend the wires for my oil pressure gauge and finish running all the wires up behind the stereo and to the top of the dash. My wife thought it would look really cool if I had the gauge holder hydrodipped in a carbon fiber look so I dropped it off today to be done. It will take a week to finish so I'll work on finishing cleaning up everything else and getting it ready to start.

I also ordered the parts for the oil filter swap so I can use the spin on oil filter and add an oil cooler. I ordered the oil cooler parts yesterday so I figured it would be best to just do the mod while I was finishing up the turbo build.

#9
First start up to check for any leaks went well. I've got wires everywhere but all the gauges work and I didn't see any leaks. I let it idle for 10-15 minutes per the instructions and let it get up to operating temperature. The new higher flow fuel injectors are louder than OEM but in person they aren't noticeable like in the video.


#12
I was able to fabricate some mounting brackets and get the oil cooler mounted. I had to move my Hella horns up a little to get the oil cooler in the airflow but it turned out great. Waiting on the hoses to arrive now. :grin:









#13
I was able to work a little on getting everything tied up on my turbo install. Started working on getting my oil catch can mounted. Hardest part is trying to figure out where to mount it. Hoping to finish it getting it installed tomorrow. I need to get a different fitting size to fit my crankcase hose.

I did a test fit of my new engine cover that I had hydrodipped and I love it. I also need to get my gauges mounted in the gauge pod that I had dipped too.

#14
Did the oil filter conversion today!


Old vs new!


Old filter housing off!


New part installed.


All set for the spin on filter or sandwich plate for oil cooler or gauges. :grin:


I also mounted my gauges in the gauge pod that I had hydrodipped. :grin:

#16
I had my hydrodipped engine cover painted so the raised letters looked better. I love the finished product. I also mu Mishimoto oil catch can installed. The final tailpipe was also welded on and I've been driving it this week. The power is amazing even off boost. With the turbo always spinning it increases vacuum and makes the car feel so much quicker. When boost comes on the fun really begins! I highly recommend this to anyone that loves their Corolla. And the best part, I'm still getting 35-40 mpg while driving normally.





















#17
Picked up my Corolla from Fast Specialties in Vancouver, WA where they did my final tune. They asked me how I wanted my tune done, mild, medium or maximum! I told Travis the tuner that I wanted to keep it mild as I didn't want to mess up the reliability. When I got it back the final tune netted 195HP at the wheels which is about 230HP plus at the crank. He was very impressed with the quality of the turbo kit from Turbokits.com and the fit and finish was top notch he said. He could always ring out more HP he said but it's between mild and medium he told me. I'm thrilled with the final results and highly recommend this for anyone else that wants to have a unique Corolla. I've got so much more power and I'm still getting 35+ MPG.....amazing! Cruising MPG seems to be even better when I drive it like I did before on the open highway.

Many thanks to Jesse and Grant at Turbokits for all of their help with my many questions along this build. Contact them if you guys really want to make your Corolla special!

#18
I took my Corolla out for a short drive in some of the nearby hills today. I got on it a little more than before and let me tell you, I was grinning from ear to ear. It's amazing how effortlessly it pulls hills now. On some steeper hills that I would hit 45 mph by a certain point before I was at 75+ mph without even trying. I'm still running my OEM clutch and though I haven't felt it slip I want to not abuse it too much until I have a new one that can handle all the power. You simply can't imagine how fast this car is now until you experience it.

In this video a car was in front of me so i pulled off the road and waited a short moment before heading up this road on a hill. I've driven it a lot and I was hitting 75 mph without even trying before the hard 90 degree left at the top of the hill. You can hear the turbo and BO valve in the video. Now if I can only figure out why I the seat has started to squeak. I never hear it when I'm driving with the music up but when it was down to record this I heard it!

The date is wrong as I forgot to reset it before recording.


#20
Nice build. What PSI are you running? What's the turbo size?

Turbo Cobalts are around 300 with a tune to the crank... imagine that lol
Thanks. As I said in my post I had it tuned to be on the mild side as I want to keep reliability high. I'm running 8.6 PSI in the tune and it could easily do more he said but I'm fine with it. It pulls really hard and has good low end pull too. I'm not interested in just a peak power as many times that hurts drivability. Also 300HP in a FWD car this size just seems like over kill. The kit uses a custom spec'd T28 turbocharger and I upgraded it with a billet wheel for faster spool time. This is an amazing turbo kit and the quality is top notch. Some of you should look at doing this too!

#21
Love the build, I been wanting to boost my 2012 Corolla Sport for a while but I just been so hesitant to do so. Reading through your post and seeing how well your build came together definitely has motivated me to bring some new life into my Rolla.

#22
Love the build, I been wanting to boost my 2012 Corolla Sport for a while but I just been so hesitant to do so. Reading through your post and seeing how well your build came together definitely has motivated me to bring some new life into my Rolla.
I think the key is to keep it in perspective. By tuning my Corolla on the mild side I keep all the reliability but when I want or need the power it's always there. It's such a blast to drive and a complete car in every way now. I'm honestly surprised that others haven't done it more. Everyone talks about it and talks the game but they don't follow through. It's by far the best bang for the buck and HP per $$$ is far better then other mods. I would love to see you join the turbo Corolla club.

#23
I think the key is to keep it in perspective. By tuning my Corolla on the mild side I keep all the reliability but when I want or need the power it's always there. It's such a blast to drive and a complete car in every way now. I'm honestly surprised that others haven't done it more. Everyone talks about it and talks the game but they don't follow through. It's by far the best bang for the buck and HP per $$$ is far better then other mods. I would love to see you join the turbo Corolla club.
I totally agree with you on that, I would definitely tune it on the mild side to keep the reliability aspect of it. Seeing an intercooler in the front of a Corolla is a rare and special site because everybody is so use to seeing boosted civics, and then people buy the Evo's and the STI's since they come factory boosted but I think you get a far greater appreciation when you boost a corolla and know it'll outrun a lot of cars on the streets if you tune it right.

#24
I totally agree with you on that, I would definitely tune it on the mild side to keep the reliability aspect of it. Seeing an intercooler in the front of a Corolla is a rare and special site because everybody is so use to seeing boosted civics, and then people buy the Evo's and the STI's since they come factory boosted but I think you get a far greater appreciation when you boost a corolla and know it'll outrun a lot of cars on the streets if you tune it right.

#26
Sick! I want to add my turbo kit, I need some horsepower!
I'm honestly surprised that more people haven't added the turbo kit. For a very reasonable price you can make your Corolla very unique with amazing power. So much fun to enjoy and always keep as a fun car when you may add a newer car down the road.

#31
Turbokits.com, it's one of the options that you can pick from when ordering the turbo kit. There are many options you can pick from or you can stick with the standard kit. I also had my turbo, exhaust manifold and downpipe ceramic coated. If you go on the website you can look through the options. The AEM FIC comes with a wiring harness that can be wired into any vehicle but the plug-in-play harness is made to plug directly into the Corolla ECU from the AEM FIC.

#34
I think the key is to keep it in perspective. By tuning my Corolla on the mild side I keep all the reliability but when I want or need the power it's always there. It's such a blast to drive and a complete car in every way now. I'm honestly surprised that others haven't done it more. Everyone talks about it and talks the game but they don't follow through. It's by far the best bang for the buck and HP per $$$ is far better then other mods. I would love to see you join the turbo Corolla club.
:D We are all still waiting for Toyota to officially release their TRD Corolla (turbocharge) :p

#37
So, what was your final bill for your turbo investment? (be honest)

What is your advice to all of us, before venturing into this investment?

Any unforeseen headaches or do(s) & don’t(s)?
Total investment will vary depending on the options you want to pay for. The turbo kit itself starts is $2895 today. I added several options.
1. $195 - 3" cold air intake
2. $395 - Thermal coating
3. $895 - 3" SS exhaust
4. $195 - Turbo billet wheel upgrade
5. $579 - AEM Plug N Play wiring harness

So if you did what I did it would be $5154. The only option I would do for certain is the harness. I did add gauges but everything else I did was just that, optional.

I think I paid $400 to tune the car but I did the install for free. It wasn't that difficult. It's just nuts and bolts.

My biggest advice would be to call Turbokits. Talk to them. Ask questions. Jesse is the tech guy and is super helpful and so is Grant. I've personally met them both in person and they are there to help. I've never experienced any better customer service before or after the sale.

If you can afford it, do it. I love have all of the reliability of my Corolla with the extra power when I need or want it. It's a perfect marriage.

#41
SuperchargedMR2

Did you ever finish your rear drum conversion?
Nope. It's still something that I would like to do sometime but I just haven't had the time. This past year we've been short staffed at work and I've been working a lot extra. Top that off with my oldest daughter getting married this month and we've been crazy busy getting ready for that. So hopefully it will happen in the future sometime. It is still on my to do list! :cool:

#42
I just finished installing an oil catch can on my 2009 Corolla S Turbo. I also updated my HID retrofit with some new RGB halos. I also changed out my gauges as my AEM gauges just didn't fit the look I wanted. I just installed some Glow Shift gauges that allow me too change the color to match what I want.
You can see my OCC, valve cover breather and new air filter.








New RGB halos!!!


Not a good pic but I was trying to show the different colors. There are 7 to choose from.

#43
Drove my 09 Corolla S Turbo the 1024 miles down to Toyotafest last month. It was the first long drive over 200 miles I've been on since installing the turbo kit. She ran like a dream and I even got great MPG on the drive from between 35-40 MPG.


I took all back roads on the way home. Instead of the direct 1024 miles on I-5 it was a 2500 mile adventure that was amazing!


























A shot of my new gauges.
